1. Description
The AM26C31QDR device is a differential line driver with complementary outputs, designed to meet the requirements of TIA/EIA-422-B and ITU (formerly CCITT). The 3-state outputs have high-current capability for driving balanced lines, such as twistedpair or parallel-wire transmission lines, and they provide the high-impedance state in the power-off condition. The enable functions are common to all four drivers and offer the choice of an active-high (G) or active-low (G) enable input. BiCMOS circuitry reduces power consumption without sacrificing speed. The AM26C31QDR device is characterized for operation from 0°C to 70°C, the AM26C31I device is characterized for operation from –40°C to 85°C, the AM26C31Q device is characterized for operation over the automotive temperature range of –40°C to 125°C, and the AM26C31M device is characterized for operation over the full military temperature range of –55°C to 125°C.
2. Features
1. Meets or Exceeds the Requirements of TIA/EIA422-B and ITU Recommendation V.11
2. Low Power, ICC = 100 μA Typical
3. Operates From a Single 5-V Supply
4. High Speed, tPLH = tPHL = 7 ns Typical
5. Low Pulse Distortion, tsk(p) = 0.5 ns Typical
6. High Output Impedance in Power-Off Conditions
7. Improved Replacement for AM26LS31 Device
8. Available in Q-Temp Automotive
– High-Reliability Automotive Applications
– Configuration Control and Print Support
– Qualification to Automotive Standards
3. Pin Configuration and Functions
5. Dimensions
