1. Describe
TLP350 is a DIP8 packaged optocoupler, manufactured by GaA ℓAs infrared light emitting diode (LED) It is optically coupled to the integrated high-gain, high-speed photodetector IC chip. It provides guaranteed performance And specifications at temperatures up to 100 °C. TLP350 has an internal Faraday shield and can provide Ensure common mode transient immunity ±15 kV/Microseconds. It has a totem pole output, which can either sink or Source current. TLP350 is very suitable for small to medium capacity IGBT and power MOSFET gate drive.
2. Feature
1. Buffer logic type (totem pole output)
2. Output peak current: ±2.5A (maximum)
3. Operating temperature: -40 to 100°C
4. Power supply current: 2.0 mA (maximum)
5. Power supply voltage: 15 to 30 V
6. Threshold input current: 5 mA (maximum)
7. Propagation delay time: 500 ns (maximum)
8. Common mode transient immunity: ±15 kV/ µs (min)
9. Isolation voltage: 3750 Vrms (min)
10. Safety standards
3. Application
1. Industrial inverter
2. Air conditioner inverter
3. MOSFET gate driver
4. IGBT gate driver
5. Induction cooker and household appliances
4. Pin configuration
