1. Description
The LMT86DCKT are precision CMOS temperature sensors with ±0.4°C typical accuracy (±2.7°C maximum) and a linear analog output voltage that is inversely proportional to temperature. The 2.2-V supply voltage operation, 5.4-μA quiescent current, and 0.7-ms power-on time enable effective power-cycling architectures to minimize power consumption for battery-powered applications such as drones and sensor nodes. The LMT86LPG through- hole TO-92S package fast thermal time constant supports offboard time-temperature sensitive applications such as smoke and heat detectors. The accuracy over the wide operating range and other features make the LMT86 an excellent alternative to thermistors.
2. Features
1. LMT86LPG (TO-92S package) has a Fast Thermal Time Constant, 10-s Typical (1.2 m/s Airflow)
2. Very Accurate: ±0.4°C Typical
3. Low 2.2-V Operation
4. Average Sensor Gain of -10.9 mV/°C
5. Low 5.4-µA Quiescent Current
6. Wide Temperature Range: –50°C to 150°C
7. Output is Short-Circuit Protected
8. Push-Pull Output With ±50-µA Drive Capability
9. Footprint Compatible With the Industry-Standard LM20/19 and LM35 Temperature Sensors
10. Cost-Effective Alternative to Thermistors
3. Applications
1. Infotainment and Cluster
2. Powertrain Systems
3. Smoke and Heat Detectors
4. Drones
5. Appliances
