The PIC18F67K22T-I/PT is a 4 kB RAM and 128 kB flash 8-bit microcontroller with low power and high-performance. It is ideally suited for power-constrained and battery-powered applications.
The charge time measurement unit simplifies the design of capacitive touch applications and can enable other applications requiring precise time and/or temperature measurement.
Low power consumption function:
• Power management mode:
-Run: CPU is turned on, peripherals are turned on
-Idle: CPU is off, peripherals are on
-Sleep: CPU is off, peripherals are off
• Two-speed oscillator start
• Fail-safe clock monitor
• Power saving peripheral module disabled (PMD)
•Ultra low power wake up
• Fast wake-up, typical value is 1 s
• Low power consumption WDT, typical value is 300 nA
• Ultra-low 50 nA input leakage
• Run mode current is as low as 5.5A (typical value)
• Typical idle mode current is as low as 1.7A
• Sleep mode current is as low as 20 nA,typical
• The RTCC current drops to an extremely low level of 700nA,Typica
Special microprocessor functions:
• Operating voltage range: 1.8V to 5.5V
• On-chip 3.3V regulator
• Running speed up to 64 MHz
• Up to 128 KB on-chip Flash program memory
• 1,024 bytes of data EEPROM
• 4K x 8 general purpose registers (SRAM)
• 10,000 erase/write cycles flash program Minimum memory
• 1,000,000 erase/write cycles data EEPROM Memory, typical
• Flash retention: at least 40 years
• Three internal oscillators: LF-INTRC (31 kHz),MF-INTOSC (500 kHz) and HF-INTOSC(16 MHz)
• Self-programming under software control
• Interrupt priority
• 8 x 8 single cycle hardware multiplier
•Extended watchdog timer (WDT):
-Programmable period from 4 milliseconds to 4,194 seconds(About 70 minutes)
• Via In-Circuit Serial Programming™ (ICSP™) Two stitches
• Online debugging through two pins
• Programmable:
-BOR
-LVD
