1. Description
The LMZ21701SILR nano module is an easy-to-use stepdown DC/DC solution capable of driving up to 1000-mA load in space-constrained applications. Only an input capacitor, an output capacitor, a soft-start capacitor, and two resistors are required for basic operation.
2. Features
• Integrated Inductor
• Miniature 3.5 mm × 3.5 mm × 1.75 mm Package
• 35-mm² Solution Size (Single Sided)
• -40°C to 125°C Junction Temperature Range
• Adjustable Output Voltage
• Integrated Compensation
• Adjustable Soft-Start Function
• Starts into Prebiased Loads
• Power Good and Enable Pins
• Seamless Transition to Power-Save Mode
• Up to 1000 mA Output Current
• Input Voltage Range 3 V to 17 V
• Output Voltage Range 0.9 V to 6 V
• Efficiency up to 95 %
• 1.5-µA Shutdown Current
• 17-µA Quiescent Current
3. Applications
• Point-of-Load Conversions from 3.3 V, 5 V, or 12 V Input Voltage
• Space Constrained Applications
• LDO Replacement
