1. Description
The LMZ21701SILT nano module is an easy-to-use stepdown DC/DC solution capable of driving up to 1000-mA load in space-constrained applications. Only an input capacitor, an output capacitor, a soft-start capacitor, and two resistors are required for basic operation.
2. Features
1. Integrated Inductor
2. Miniature 3.5 mm × 3.5 mm × 1.75 mm Package
3. 35-mm² Solution Size (Single Sided)
4. -40°C to 125°C Junction Temperature Range
5. Adjustable Output Voltage
6. Integrated Compensation
7. Adjustable Soft-Start Function
8. Starts into Prebiased Loads
9. Power Good and Enable Pins
10. Seamless Transition to Power-Save Mode
11. Up to 1000 mA Output Current
12. Input Voltage Range 3 V to 17 V
13. Output Voltage Range 0.9 V to 6 V
14. Efficiency up to 95 %
15. 1.5-µA Shutdown Current
16. 17-µA Quiescent Current
3. Applications
1. Point-of-Load Conversions from 3.3 V, 5 V, or 12 V Input Voltage
2. Space Constrained Applications
3. LDO Replacement
